Type S7
Double Stage Pressure Regulators for North America
Designed for residential and light commercial use, it ensures accurate pressure control and built-in overpressure protection, including OPSO, UPSO, and EFV options. Reliable, safe, and optimized for North America.
For more information click here.
SPECIFICATIONS
Approvals:
- ANSI B109.4, EN88-2
Inlet Pressure:
- Up to 125 psig (8.6 barg)
Outlet Pressure Ranges:
- Base Pressure (BP): 6” w.c. to 2.6 psig, Medium Pressure (MP): 2.6 to 5.8 psig
Regulating Accuracy Classes:
- +2/-1” w.c., +/- 2” w.c., +/- 1% ABS, +/-2% ABS, AC5, AC10
Working Temperature Range
- -22oF to 140oF (-30oC to 60oC)
Body Configurations
- Linear or angled body (outlet on bottom), 3/4 x 3/4″ NPT, 3/4 x 1” NPT, 1 x 1” NPT
