Type S4
Double Stage Pressure Regulators
The S4 series regulators are a line of direct action type pressure regulators, double stage, normally used for domestic applications, if directly assembled to the meter or in decompression installations in gas grids and industrial uses for natural and manufactured gas, lpg, or other non-corrosive preliminarily treated stable gas.
SPECIFICATIONS
Body Material: Zamak
Inlet Pressure: 0.5 ÷ 5 / 0.8 ÷ 5
Outlet Pressure: 14 ÷ 100 / 100 ÷ 500
Nominal Capacity: Up to 100 Nm³/h
Working temperature: – 20 °C ; + 60 °C
Inlet Connections: 1″”1/4; 1″”; 3/4″”
Outlet Connections: 1″”; DN32; 1″”1/4; 1″”1/2; DN40, DN50; 2″”
